GATE IT 2006 | Question: 78

• edited by
15,865 views
46 votes
46 votes

A pipelined processor uses a $4-$stage instruction pipeline with the following stages: Instruction fetch (IF), Instruction decode (ID), Execute (EX) and Writeback (WB). The arithmetic operations as well as the load and store operations are carried out in the EX stage. The sequence of instructions corresponding to the statement $X = (S - R * (P + Q))/T$ is given below. The values of variables $P, Q, R, S$ and $T$ are available in the registers $R0, R1, R2, R3$ and $R4$ respectively, before the execution of the instruction sequence.
$$\begin{array}{ll} \text{ADD} & \text{R5, R0, R1} && \text{; R5 ← R0 + R1} \\  \text{MUL} & \text{R6, R2, R5} && \text{; R6 ← R2 * R5} \\   \text{SUB} & \text{R5, R3, R6} && \text{; R5 ← R3 - R6} \\  \text{DIV} & \text{R6, R5, R4} && \text{; R6 ← R5/R4} \\ \text{STORE} & \text{R6, X} && \text{; X  ← R6} \\ \end{array}$$
The number of Read-After-Write (RAW) dependencies, Write-After-Read( WAR) dependencies, and Write-After-Write (WAW) dependencies in the sequence of instructions are, respectively,

  1. $2, 2, 4$
  2. $3, 2, 3$
  3. $4, 2, 2$
  4. $3, 3, 2$
• edited by
User Avatar

2 Answers

Best answer
53 votes
53 votes

(C) is the correct option for this question:

RAW

  1. I1 - I2 (R5)
  2. I2 - I3 (R6)
  3. I3 - I4 (R5)
  4. I4 - I5 (R6)


WAR

  1. I2 - I3 (R5)
  2. I3 - I4 (R6)


WAW

  1. I1 - I3 (R5)
  2. I2 - I4 (R6)
• edited by
User Avatar
Voting & Accepting an answer helps improve the community
Answer:
